云南铝板厂-昆明铝单板幕墙应用

您的当前位置: 首 页 >> 产品中心 >> 幕墙氟碳铝单板

云南铝板厂-昆明铝单板幕墙应用

  • 所属分类:幕墙氟碳铝单板

  • 点击次数:
  • 发布日期:2019/04/16
  • 在线询价
  • 详细介绍



云南铝板厂——云南亚太铝业有限公司为您介绍一下昆明氟碳铝单板幕墙应用,氟碳铝单板幕墙在生产的时候是有标准的,下面具体来看看:

本标准规定了喷涂氟碳(聚偏二氟乙烯)漆的幕墙用铝及铝合金单层成形板,适用于表面经氟碳漆 喷涂处理的铝幕墙用铝单板。

This standard specifies PVDF (Poly Vinylidine DiFluoride) coated curtain wall aluminums and single aluminum alloy panels , applicable to single aluminum alloy panels for curtain walls performed PVDF surface coating。



铝合金型号Aluminum Alloy Model No

抗拉强度 Tensile Strength

屈服强度Bending Strength

延伸率% Enlongation(%)

折弯内侧半径(厚度为2mm)Inner radius of bending (2mm thickness)

A5052H44

230-280

180

5以上 Above5

R=2mmx2.5

A3003H44

210-265

180

4以上 Above4

R=2mmx2



铝合金型号Aluminum Alloy Model No

抗拉强度Tensile Strength

屈服强度

延伸率%

折弯内侧半径(厚度为2mm)Inner radius of bending (2mm thickness)

A1050H44

230-280

180

4以上 Above4

R=2mmxl

A1200H44

210-265

180

4以上 Above4

R=2mmxl

A3004H44

210-265

180

4以上 Above4

R=2mmxl.5

A3005H44

230-280

180

3以上 Above3

R=2mmxl.5

A5754H44

210-265

180

6以上 Above6

R=2mmxl.5





H后第一位数字代表板材处理的方式

The 1st number after "H"stands for the manufacturing methods of the Aluminum panel

•直接退火(先热轧-后冷轧)

•淬火(先热轧-后冷轧)

•烤漆(back)后加压、升温从H14-H34的有滚涂后的板材都转化为40H前4位代表合金种类

•Cool directly (Hot Roll first-then Cold Roll)

•Quenching(Hot roll first-then Cold Roll)

•The panels ranging from HI4-H34 after roll painting and raise pressure and temperature for paint baking purpose transform to 4H. And the first four digits stand for the type of the alloy.

H后第二位数字代表板材硬度

The second number after"H"stands for the hardness of the Aluminum panel

♦2-25%硬度(1/4 fwdneSS)M-50%硬度(1/2 hardness)^6-75%5fJt(3/4 hardness)

♦8-100%全硬度(1 hardness)♦2-25%Hardness( 1/4 hardness)^4-50%Hardness(1/2% hardness)

♦6-75% Hardness(3/4 hardness)*8_100% Full Hardness(1 hardness)
